4 Core SWA Cable

240mm 4 core swa cable

240mm 4 Core SWA Cable

  • Brand Name: HuaDong Cable
  • Voltage: up to 35 KV
  • Armoured: SWA (Steel Wire Armoured)
  • Insulation: XLPE / PVC / LSZH / Fire Resistant
  • Core identification: Brown, Black, Grey & Blue
  • Sheath / Jacket: PVC; Color: Black
  • Email: huadong@hdcablegroup.com
  • Discount Price

What is 240mm 4 Core SWA Cable?

240mm 4 Core SWA Cable or Steel wire armoured cable is a hard-wearing cable made up of Black PVC Sheath, xlpe insulation, copper conductors and steel wire armouring.240mm 4 Core SWA Cable is designed for mains electricity for laying underground, power networks, incoming mains to homes amongst a host of other applications externally and internally.
240mm 4 Core SWA Cable is also handy as it allows the user to use the cable for direct burial and the armour enables the cable to withstand higher pulling loads.The XLPE insulation is resistant to a number of different fluids, chemicals and has good heat stability.

240mm 4 Core SWA Cable Specifications :

Insulation: XLPE (cross-linked polyethylene)
Bedding: PVC (polyvinyl chloride)
Armouring: multi core: SWA (steel wire armour)
Sheath: PVC (polyvinyl chloride)
Sheath colour: Black (carbon loaded for UV stability)
Core colours: Brown / Black / Grey / Blue
Voltage rating: 600/1000v
Temperature rating: -15ºc to +90ºc
Nominal overall diameter: 62mm

240mm 4 Core SWA Cable Construction :

Conductor: Class 2 Plain Stranded Copper (Cu) Conductor
Insulation: Cross-Linked Polyethylene (XLPE) is used as insulation in many power cables, due to its excellent electrical properties and water resistance. It also ensures that conductors and other metal substances do not come into contact with each other.
Bedding: Polyvinyl Chloride (PVC) is used as bedding to provide a protective boundary between inner and outer layers of the cable.
Armouring: Steel Wire Armour (SWA) used for mechanical protection. That way the cable can withstand higher stresses, be buried directly and used in external or underground projects.
Sheath: Polyvinyl Chloride (PVC) Sheath holds all the components together and provides additional protection from external damage.

240mm 4 Core SWA Cable Advantages :

If you use the 240mm 4 Core SWA Cable in some public places, for example: medium school, big hospitals, plaza etc. You must buy the LSZF (Low Smoke Zero Halogen) 240mm 4 Core SWA Cable or LSHF Cable (Low Smoke Halogen Free) that its insulation materials are low-pressure halogen-free fireproof. The LSHF 240mm 4 Core SWA Cable will is very safer than other common 240mm 4 Core SWA Cable. Especially, once there is a danger fire hazard. So, that’s why the LSHF 240mm 4 Core SWA Cable prices is higher than other cables. But, you also testing the insulation’s flame retardant and fire resistance before bury the cable.

240mm 4 Core SWA Cable why choose HuaDong?

Huadong Cable Group as a special 240mm 4 Core SWA Cable factory in China, We not only have over 30 years of production experience and 15 years of export experience in 240mm 4 Core SWA Cable, but also we have 15 senior engineers, they can free design the 240mm 4 Core SWA Cable size according to client’s requirement.
Our 240mm 4 Core SWA Cable export such as South Africa, Philippines, Indonesia, Malaysia, Singapore, Vietnam, Korea, Mongolia, Yemen, Cambodia, Thailand, Kenya, Tanzania, UAE, Botswana,Nigeria, Panama, Iran etc.High quality service and production are the first choice of many customers.

For the best 240mm 4 core swa cable price, Please feel free to leave your requirement, We will reply you in 12 hours.
