600V RE-2PNCT RE-3PNCT RE(V)-2PNCT-RF Cable

600V RE-2PNCT RE-3PNCT RE(V)-2PNCT-RF Cable Description:

What is 600V RE-2PNCT RE-3PNCT RE(V)-2PNCT-RF Cable? Do you know RE-2PNCT / RE-3PNCT / RE(V)-2PNCT-RF Cable meaning? Huadong Cable Group tell you all you wanna to know: 600V means Rated Voltage is 600V. RE means the main application is Reel system. PNCT is Cable Type: (Insulation: EP rubber) (Sheath: Chloroprene).

①Rated Voltage	②Main Application	③Class	④Cable Type	⑤Option (shield, etc.)
600V 3300V 6600V －	CUR (Festoon system) SK (Festoon system, flat cables) CAR (Carrier drum system) RE (Reel system) RE(V) (Vertical reel system) H (Reel system, flat cable) TOR (Torsion system) T (Vibration resistant) SPD (Spreader) F (Composite cable) FG (Optical composite cable) K (Instrumentation cable with low voltage circuit (60V or less))	2 (class 2) 3 (class 3) 4 (class 4) －	PNCT (Insulation: EP rubber) (Sheath: Chloroprene) VCT (Insulation: PVC) (Sheath: PVC) FFCT (Insulation: Fluonlex) (Sheath: Fluonlex)	SB (Overall shield) PSB (Pair shield) CSB (Individual core shield) SX (Special shield) B (Glass tape and stainless braid) RF (Reinforced sheath)

600V RE-2PNCT Cable Constructure:

Conductor: Copper /Tinned annealed copper
Insulation: EPR compound
Rubber filler
Tape
Outer sheath:Chloroprene rubber
Rated Voltage: AC 600V
Rated Temperature: 80 degrees C
Test Voltage: 3000V /1 minute
Feature: High resistance to lateral pressure and bending
Application: Suitable for the reel systems (manually wound) for crane travel, etc.

600V RE-2PNCT Cable Specification:

No. of Cores	Conductor			Insulation Thickness (mm)	Sheath Thickness (mm)	Approx. Overall Diameter (mm)	Approx. Mass (kg/km)
	Size (mm2)	Construction (No./mm)	Outer Diameter (mm)
3	8	3/0.32TST+50/0.45TA	3.8	1	2.2	18	515
	14	88/0.45TA	4.9	1	2.3	21	650
	22	7/20/0.45TA	7	1.2	2.7	26	1030
	30	7/27/0.45TA	8.1	1.2	2.8	29	1300
	38	7/34/0.45TA	9.1	1.2	3	31	1580
	60	19/20/0.45TA	11.6	1.5	3.4	39	2440
4	38	7/34/0.45TA	9.1	1.2	3.1	34	2070
6	3.5	3/0.32TST+45/0.32TA	2.6	0.8	2.2	18	505
8	3/0.32TST+50/0.45TA	3.8	1	2.5	24	950
10	3.5	3/0.32TST+45/0.32TA	2.6	0.8	2.6	24	820
12	3.5	3/0.32TST+45/0.32TA	2.6	0.8	2.6	25	925
16	3.5	3/0.32TST+45/0.32TA	2.6	0.8	2.8	28	1200
20	3.5	3/0.32TST+45/0.32TA	2.6	0.8	3	31	1480
24	3.5	3/0.32TST+45/0.32TA	2.6	0.8	3.1	34	1760
30	3.5	3/0.32TST+45/0.32TA	2.6	0.8	3.3	37	2130

600V RE-3PNCT Cable Specification:

No. of Cores	Conductor			Insulation Thickness (mm)	Thickness of Reinforcement (mm)	Sheath Thickness (mm)	Approx. Overall Diameter (mm)	Approx. Mass (kg/km)
	Size (mm2)	Construction (No./mm)	Outer Diameter (mm)
3	8	3/0.32TST+50/0.45TA	3.8	1.2	0.5	3.1	22	665
	14	88/0.45TA	4.9	1.2	1	3.3	26	940
	22	7/20/0.45TA	7	1.6	1	3.7	32	1490
	30	7/27/0.45TA	8.1	1.6	1	3.9	35	1830
	38	7/34/0.45TA	9.1	1.6	1	4	37	2170
	60	19/20/0.45TA	11.6	2.1	1	4.5	45	3360
4	38	7/34/0.45TA	9.1	1.6	1	4.2	40	2720
6	3.5	3/0.32TST+45/0.32TA	2.6	1.2	0.5	3.2	24	730
	8	3/0.32TST+50/0.45TA	3.8	1.2	0.5	3.5	28	1180
10	3.5	3/0.32TST+45/0.32TA	2.6	1.2	1	3.7	32	1190
12	3.5	3/0.32TST+45/0.32TA	2.6	1.2	1	3.7	33	1320
16	3.5	3/0.32TST+45/0.32TA	2.6	1.2	1	3.9	36	1650
20	3.5	3/0.32TST+45/0.32TA	2.6	1.2	1	4.1	40	2000
24	3.5	3/0.32TST+45/0.32TA	2.6	1.2	1	4.4	44	2400
30	3.5	3/0.32TST+45/0.32TA	2.6	1.2	1	4.5	46	2830

RE(V)-2PNCT-RF Cable Specification:

No. of Cores	Conductor			Insulation Thickness (mm)	Thickness of Reinforcement (mm)	Sheath Thickness (mm)	Approx. Overall Diameter (mm)	Approx. Mass (kg/km)
	Size (mm2)	Construction (No./mm)	Outer Diameter (mm)
7	3.5	3/0.32TST+45/0.32TA	2.6	0.8	0.5	3.1	22	670
	5.5	3/0.32TST+70/0.32TA	3.2	1	0.5	3.4	26	990
10	3.5	3/0.32TST+45/0.32TA	2.6	0.8	1	3.4	27	1010
	5.5	3/0.32TST+70/0.32TA	3.2	1	1	3.7	32	1480
13	3.5	3/0.32TST+45/0.32TA	2.6	0.8	1	3.7	32	1370
	5.5	3/0.32TST+70/0.32TA	3.2	1	1	4	38	2020

600V RE-2PNCT RE-3PNCT RE(V)-2PNCT-RF Cable Why Choose Huadong

As a professional 600V RE-2PNCT RE-3PNCT RE(V)-2PNCT-RF Cable manufacturer, HuaDong has over 30 years of production experience and 15 years of export experience.Our 600V RE-2PNCT RE-3PNCT RE(V)-2PNCT-RF Cable export such as South Africa, Philippines, Indonesia, Malaysia, Singapore, Vietnam, Korea, Mongolia, Yemen, Cambodia, Thailand, Kenya, Tanzania, UAE, Botswana,Nigeria, Panama, Iran etc.High quality service and production are the first choice of many customers.
