HMWPE Cathodic Protection Cable

What is HMWPE Cable

HMWPE cable is a cable generally used for cathodic protection; it consists of stranded copper conductor separated from it’s insulation a layer of High Molecular Weight Polyethylene. This tough insulation offers superior protection against abrasion, crush, moisture, and chemicals and conforms to HMWPE cable for direct burial in pipeline, storage tanks, marine, and other wet-buried metallic structures.

HMWPE Cable Construction

	Cu/HMWPE	Cu/PVDF/HMWPE	Cu/HMWPE/PVC/SWA/SWA/HMWPE	CU/LDPE/NYLON/LDPE
Nominal voltage	600 V
Operating temperature	75 °C
Conductor	Stranded Annealed Copper
Insulation	High Molecular Weight Polyethylene (Black)	Polyvinylidene Fluoride (PVDF)	High Molecular Weight Polyethylene (Black)	LDPE(Black)
Inner Sheath	-		PVC (Black)	Nylon(Black)
Outer Sheath	-	High Molecular Weight Polyethylene (Black)	High Molecular Weight Polyethylene (Black)	LDPE(Black)

HMWPE Cable Specification

CONDUCTOR GAUGE（AWG）	NUMBER OF WIRES	CONDUCTOR DIAMETER（in）	INSULATION THICKNESS（in）	NOMINAL EXTERNAL DIAMETER（in）	NOMINAL TABLE（Lb./1000ft）	RESISTANCE MAX at 20°C（Ω/1000ft）
14	7	0,0726	0,110	0,293	39,7	2.57
12	7	0,0915	0,110	0,311	50,0	1.62
10	7	0,116	0,110	0,340	65,6	1.02
8	7	0,146	0,110	0,370	89,1	0,652
6	7	0,184	0,110	0,400	125	0,411
4	7	0,232	0,110	0,450	181	0,258
2	7	0,292	0,110	0,510	267	0,162
1	19	0,332	0,125	0,580	337	0,129
1/0	19	0,373	0,125	0,620	412	0,102
2/0	19	0,419	0,125	0,660	506	0,081
3/0	19	0,470	0,125	0,720	623	0,064
4/0	19	0,528	0,125	0,770	769	0,051

HMWPE Cable Applications

HMWPE cable is used in a variety of applications including municipal water towers, oil containment units, steel pipelines, oil drilling rigs, cathodic protection wells containing anodes, bridges, parking garages, municipal fire hydrants, and concrete structures. It is also used in gas lines that have not been replaced with plastic. Beyond that, with underground steel piping, HMWPE wire is a great wire type. HMWPE cable is used for interconnecting the cathode which is the structure to be protected and the anode which is the sacrificial in an ICCP system.
